• No.:TS-J50ZS
  • Name:TS-J50ZS-S TAISHENG Auto Framing Joint Robot - Small size
  • view:3072

Product Description

IFeatures
This machine can joint 4 corner together in one time , only need worker loading frame
sticks in machine . After start work , TS-J50ZS will push sticks one by one to finish
automatic joint. Easy to get 1600-2400pcs frame per hour.
Fast speed makes it can helps you easy set up a automatic production line . Any new
worker can handle large production qty easy!
Automatic cutting machine available in TAISHENG too , TS-J39 QPJ cutting machine,
Cut 30pcs frame sticks in a dozen / time. A good partner of TS-J50ZS .Call TAISHENG ,

Get more details .




How it is in production line :



IIAdvantage
1. Adopt precision transmission, servo motor, step motor, etc.
2. Adopt touch screen interface, good visibility and easy to use.
3. Fast production, 1600-2400pcs frame /hour .the output is 20-40pieces per minute,
   (Example: stable output can reach 4 0 pieces per minute with one v nail per corner,
   and 25 pieces per minute with two v nails per corner).
4. All high quality steel bone ,makes machine won't shake or out of shape.
5. Big size one has frame parking port in middle,the platform will helps big size frame
   carefully go down and move to next station smoothly.
6. V nail groove can loading 1200pcs in one time ,easy load more during working time.
7. New frame loading port,funnel shape design. Makes frame sticks easy put into it.
8. Four corner joint in one time ,keep all corner in perfect joint condition
9. Any new worker can handle large production easy,only need move sticks to machine.
IIITechnical data
1. Formation frame: precision guide, ball screw
2. Operation mode: manual/automatic
3. Control mode: touch screen interface control
4. Feeding mode: manual loading frame sticks
5. Air pressure: over 0.7Mpa
6. Electric power: 380V,50hz, 3 phase Or 220V,50/60hz, 1 phase .

7. Total power: 5.7KW.


Machine detais :  It has 2 type .



How to use it ? Manual video as below :



Delivery packing :

Buyer show :


Automatic cutting machine partner :TS-J39 Automatic cutting -28pcs frame cutting in one time!

Click picture Learn more : http://taishengframe.com/en-US/product829.html





Automatic Frame Joining PRODUCTION LABOR SAVINGS|FRAME BUILDING INTEGRATION Designed and
manufactured for high-volume auto joining of canvas stretcher bars. Average cycle time for four-corner
joining is 2 to 6 seconds per frame. Production range up to 1600-2400 joined frames per hour.
TS-J50ZS TAISHENG Frame Robot System suited for high volume automatic frame joining of moulding and
canvas stretcher bars. The system consist of aVertical Feeder that automatically positions the moulding into
the four individually controlled joining stations each inserting V-Nails simultaneoulsy in one or multiple
positions per corner.
автоматиЧескаа фоторамка CKPEПЛЯОЩИЙ CTAHОK CкреплЯоЩий cтaнok “TS-J50ZS” большe
подходит дла багетных мастерских, выполнаоцих индивидуальные заказы. yдобный, надекдный и
производительный станок, прост в управлении. верхний приким всегда находитсЯ в тоЧке, где
вставлЯетCЯ скобка.
TS-J50ZS automatically underpins four stretcher bars (45°cut) with v-nails.
Frames can be underpinned adjustably with one, two or three v-nails. You can expect production yields of
about 30-40 units per minute, depending on if your operator can keep up with the magazine loading and
frame output handling.
Format changes are continuously variable and take approximately 2 minutes with no extra tools needed.
Through its integration into automated canvas stretching manufacturing,


Online order and more details please check link as below:https://www.alibaba.com/product-detail/TS-J5OZS
Automatic-picture-frame-joint_1600632546687.html?spm=a2747.manage.0.0.68ee71d2R0jPJD


TS-J50ZS-Small Automatic Frame Joining robot PRODUCTION LABOR SAVINGS| FRAME BUILDING INTEGRATION
Designed and manufactured for high-volume auto joining of canvas stretcher bars. Average cycle time for
four-cornerjoining is 2 to 6 seconds per frame. Production range up to 1800-2400 joined frames per hour.

TS-J50ZS TAISHENG Frame Robot System suited for high volume automatic frame joining of moulding and
canvas stretcher bars. The system consist of a Vertical Feeder that automatically positions the moulding into
the four individually controlled joining stations each inserting V-Nails simultaneoulsy in one or multiple
positions per corner.
Frame Assembly Machine Stretcher Bar underpinner machine vnails joint machine #StretcherBar
